High Power Mobile Signal Booster | All Networks | 600 sq.m.

Cellphone Phone Booster -600 sq.m. (Power Line)

(All ZA Operators)

Overview
Technical Specifications

If you are tired of battling your horrible mobile signal, don’t be discouraged, you haven’t tried everything yet. Give this great mobile signal booster a go and watch your connection accelerate to full speed in no time! Operating the device and installing it is a piece of cake. All you’ll need is an installation kit, containing all of the parts, plus a simple instruction to guide you. You’ll be able to enjoy a perfect reception after only a few easy steps! But if you do feel lost at any point, feel free to contact our 24/7 customer support line and our professional staff will help you resolve the issue. All of our products will be delivered to you free of charge, along with a 2-year warranty, and a 30-day money-back guarantee.

Technical Sheet
Coverage

up to 600 sqm
Use

Medium Home
Large Home
Large Office
Small Hotel
Operator

Vodacom (2G, 3G, 4G)
MTN (2G, 3G, 4G)
Cell C (2G, 3G, 4G)
Telcom (2G, 4G)
Frequency

900/1800/2100 MHz
Number of simultaneous users

100
Up-link

890 ~ 915 MHz
1710 ~ 1785 MHz
1920 ~ 1980 MHz
Down-link

935~ 960 MHz
1805~ 1880 MHz
2110 ~ 2170 MHz
Voltage

AC90-264V,output DC 5V / 3A
Dimensions

350x230x50 mm.
Weight

5.8 kg

Max Gain

≥ 70dB
Max .Output Power

Up link :≥ 20dBm
MGC ( Step Attenuation )

≥ 31dB / 1dB step
Automatic Level Control

≥ 20dB
Spurious Emission & Output inter-modulation
- GSM Meet ETSI TS 151 026 V 6.1.0
- WCDMA Meet 3GPP TS 25.143 ( V 6.2.0 )
- CDMA Meet IS95 & CDMA2000
Gain Flatness
- GSM & CDMA

  Tpy≤ 6dB(P-P); DCS,PCS ≤ 8dB(P-P)
- WCDMA

  ≤ 2dB/ 3.84MHz,Full Band ≤ 5dB(P-P)
Noise Figure

≤ 5dB
VSWR

≤ 2.0
Group Delay

≤ 1.5μs
Frequency stability

≤ 0.01ppm
Spurious Emission & Output inter-modulation
- GSM Meet ETSI TS 151 026 V 6.1.0
- WCDMA Meet 3GPP TS 25.143 ( V 6.2.0 )
- CDMA Meet IS95 & CDMA2000
WCDMA System
- Spurious Emission Mask

  Meet 3GPP TS 25.143 ( V 6.2.0 )
- Modulation Accuracy

  ≤ 12.5%
- Peak Code Domain Error

  ≤ -35dB@Spreading Factor 256
CDMA System
- Rho

  ρ > 0.980
- ACPR

  Meet IS95 & CDMA2000
I /O Port

N-Female
Impedance

50 ohm
Operating Temperature

-25ºC~+55ºC
Environment Conditions

IP40
Dimensions

310×270×60mm
Weight

≤ 4 Kg
LED
- Power LED

  Power Indicator
- UL LED

  Be lighted when there is phone calling
- DL 1

  Light is on when Outdoor signal is -65dB
LED
- DL 2

  Light is on when Outdoor signal only -55dB
- DL 3

  Light is on when Outdoor signal only -50dB

FAQ

Why a mobile signal booster is the best solution for poor reception?

A Mobile signal booster is the only working solution if you have a weak signal and dead zones. It helps to improve signal strength so you can access the internet more quickly, and stream videos without buffering.

With our booster you can make and receive calls without interruption, ensuring you're always in touch with your family and friends.

In general, the booster catches the signals from the nearest cell tower in the area by the external antenna which is included in the kit, then it sends the signal to the booster box. The box amplifies the signals, ensuring reliable coverage even in areas with poor signal strength, and the internal antenna spreads the signals inside the closed area.
Please, help me to find the best booster. How do I know which one?
If you want to find the best booster for you there are 2 easy options:
- Use our Booster Finder Wizard to find the best booster based on your needs.
- If you're still having trouble finding the right booster after using the Wizard, contact our technical support team via chat or phone. They'll be happy to assist you in finding the best solution.
What makes Your Boosters different?

1. At Signalboosters.co.za, we are committed to providing high-quality boosters at unbeatable prices.

2. Since 2010, we've been dedicated to improving cellular signals with our specialized boosters, putting our CUSTOMERS FIRST every step of the way.

3. Our boosters fix more than the signal. DoCall customers enjoy fewer dropped calls, better voice quality, faster internet speeds, and improved video streaming.

4. In addition, we provide peace of mind with our industry-leading 24/7 after-sale service:

- Lifetime Support

- 2-Year Warranty

- Installation Services (for enterprise solutions)

5. And if it’s not a perfect solution for you, we’ll refund your purchase or replace it. No hard feelings.
Does this need installation? Can I set this up myself?

Installing our boosters is easy - in fact, 98% of our customers do it themselves. The device is plug-and-play, so all you need to do is attach the units with cables and mount the antennas. We provide simple installation guides and videos to help you along the way.

Moreover, we offer technical aftersales support after the delivery of your device, so you can have peace of mind knowing we're here to help.

How it works

Outside Antenna

The outside antenna communicates back and forth with nearby cell towers.

Booster

The signal booster amplifies any cell signals it receives from the outside antenna.

Inside Antenna

The inside antenna broadcasts these signals of use throughout your home.

Outside Antenna

The outside antenna communicates back and forth with nearby cell towers.

Booster

The signal booster amplifies any cell signals it receives from the outside antenna.

Inside Antenna

The inside antenna broadcasts these signals of use throughout your home.
